    1200x1920 Portable TFT Display 10.1 Inch LCD Screen MIPI Interface 280cd/m2

    Ask Lasest Price
    Brand Name : HG
    Model Number : HG101WU008T01
    Certification : ROHS/CE/ISO9001
    Price : Negotiation
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 300Kpcs/month
    Delivery Time : 7-15working days
    • Product Details
    • Company Profile

    1200x1920 Portable TFT Display 10.1 Inch LCD Screen MIPI Interface 280cd/m2

    10.1-inch LCD screen is a MIPI interface, TFT, full perspective, resolution of 1200 * 1920 portable TFT display

    Product description

    10.1-inch LCD screen is a MIPI interface, TFT, full perspective, resolution of 1200 * 1920 portable TFT display, used for industrial handheld and related products


    Product parameter details

    ModelHG101WU008T01ModelIndustrial handheld
    Size10.1 inchSize1200*1920
    Display size135.36mm*216.58mmDisplay size148.4mm*253.4mm*4.1mm
    Viewing AngleALLViewing Angle

    280cd/m2(customizable)

    Contrast ratio1000Contrast ratio67%
    Signal typesMIPI interface 25PIN
    TemperatureOperating temperature: -10℃ ~ + 60℃, storage temperature: -20℃ ~ + 70℃
    TP structureG+GCover plate0.7mm Dragon trace of the second generation
    TP ICILI2511TP interfaceI²C
    Remark:

    1200x1920 Portable TFT Display 10.1 Inch LCD Screen MIPI Interface 280cd/m2


    Description of products

    HG10WU008T01 is a LCM+CTP, full view of portable TFT touch screen,

    The resolution is 1200*1920, and the effect is IPS

    It is composed of TFT LCD panel, driver IC, FPC, backlight source and CTP.

    Using MIPI-4 channel interface 25PIN, can work at -10℃~60℃, storage temperature: -20℃~70℃

    This product is widely used in industrial control, medical, handheld, security, vehicle, instrumentation and other related products

    All products are available with or without touch and industrial drive boards, no matter what configuration you choose,

    Can be customized according to your requirements (can be customized backlight, FPC, touch screen, industrial drive board)

    It also meets RoHS and CE certification standards

    If you can't find a suitable one, please contact us for a recommendation.

    1200x1920 Portable TFT Display 10.1 Inch LCD Screen MIPI Interface 280cd/m2


    Packing and Shipping

    Packing Details:

    1. All products are packed in the correct way to ensure safety.

    2. For small size products, we use pallets = cartons.

    3. For larger sizes, we use knife card + foam + carton.

    4. We can also design packing according to customer's requirement.

    Transport

    1200x1920 Portable TFT Display 10.1 Inch LCD Screen MIPI Interface 280cd/m2
